Name: VDN301 ULVAC Rotary Vane Vacuum Pump, 220V 210W 44L/min Single-Stage
Brand: AMG Hydraulic Engineering
SKU: 1600317621176
Price: 6189.00 AUD
Availability: InStock

VDN301 ULVAC Rotary Vane Vacuum Pump, 220V 210W 44L/min Single-Stage

$6,189.00 $9,283.00

Shipping calculated at checkout.

Product Overview

The VDN301 ULVAC rotary vane vacuum pump is a compact, oil-sealed vacuum pump manufactured in Japan, designed for precision vacuum applications in medical and machining environments. It provides stable and reliable vacuum performance for small-scale systems.

With a pumping speed of 44 L/min and a single-phase 220V motor, this pump is ideal for vacuum chuck systems, laboratory equipment, and automated machinery.

Technical Specifications

Specification	Value
Product Name	Rotary Vane Vacuum Pump
Model	VDN301
Brand	ULVAC
Pump Type	Vacuum Pump
Structure	Single-Stage Rotary Vane
Pressure	Vacuum Pressure
Ultimate Pressure	1.2 × 10³ Pa
Flow Rate	44 L/min
Speed Range	Standard motor speed
Motor Type	Single-Phase Capacitor Run
Power Source	Electric
Power Rating	210 W
Voltage	220V
Frequency	50 / 60 Hz
Pump Body Material	Industrial Alloy
Sealing Type	Oil-Sealed
Certification	CE
Suitable Media	Air
Application Scope	Medical / Machining
Dimensions	Model dependent
Warranty	12 Months

Key Features

Compact single-stage rotary vane design
Pumping speed of 44 L/min
Stable and reliable vacuum performance
Single-phase 220V operation
Suitable for continuous-duty applications
High-quality Japanese manufacturing

Typical Applications

Medical equipment
Vacuum chuck systems
Machining applications
Laboratory equipment
Automation systems
Air evacuation systems

Shipping & Support

Fast dispatch - Australia & World wide shipping
Technical assistance available
12-month warranty
